HOW TO MAKE A PASSWORD GENERATOR USING BRAINFUCK (PART 1/3)

2025-01-05 14:10 • 10 min read • #bash #brainfuck #terminal #c

DISCLAIMERS

FUNKY INTRODUCTION

For those who don't know BrainFuck, it's an esoteric programming language with only 8 commands (<>+-[],.) created by Urban Müller in 1993.

Yeah, basically, a programming language invented to FLEX in front of your dev friends/collegues (sorry for this bad joke).

But hey, it's a fun language i discovered 4 years ago without given too much attention on it, and in the recent weeks i challenged my self to give it a "REAL TRY" (just to cap...).

It's a Turing-complete language, so it has loops, iterations, shifts, you can even make arithmetics operations with it (CRAZY RIGHT ???).

This is an example of Brainfuck code :

>>+>>[<++>-]>+<<-

Yeah... much more like an ancient tribe sorcery summoning something not fun... lmao.

But, hey, you can even mimic if-else conditionals logic (that you can artificially create with loops and memory manipulation)

HOW DOES THIS WEIRD THING ACTUALLY WORK ?

The idea behind brainfuck is JUST memory manipulation.

Basically you are given an array of 30,000 1byte memory blocks.The array size is actually dependent upon the implementation used in the compiler or interpretor, but standard brainfuck states 30,000 (in my case i will deal first with 8 only)

Within this array, you can increase the memory pointer, increase the value at the memory pointer, etc, am not going to go to much in depth here how operators works in brainfuck :

> = increases memory pointer, or moves the pointer to the right 1 block.
< = decreases memory pointer, or moves the pointer to the left 1 block.
+ = increases value stored at the block pointed to by the memory pointer
- = decreases value stored at the block pointed to by the memory pointer
[ = like c while(cur_block_value != 0) loop.
] = if block currently pointed to's value is not zero, jump back to [
, = like c getchar(). input 1 character.
. = like c putchar(). print 1 character to the console

Don't worry if you didn't get any of what i just said up there, it's normal, i had the same facial expression as yours at this moment, when i was learning about it.

However, saying it's turing complete, doesn't means you can do anything with it, like sending people into Mars you know ?

So CHILL Mr ROBOT, "we don't do that here".

It's most-likely memory blocks manipulation only.

YES, there are some freaks out there doing game engines with it... am a human trying to have a normal life okay ? am not going to explain how they did that.

LET's TEST THIS THING, SHALL WE ?

You will need an intepreator to test your bf code, it looks like, the most popular is bf, even tho it looks a little old,

you can install on your OS (for these blog posts, am working on Linux, the best OS By The Way), specially Ubuntu.

# so, on DEB distro, you can just
$ sudo apt update
$ sudo apt install bf

# Or better, you can compile it yourself (if you're a real CHAD):
$ git clone https://github.com/fabianishere/bf && cd ./bf
$ make
$ sudo make install # to install on system-wide
$ bf -h

Let's test some "random bf code":

$ echo "++++++++[>++++[>++>+++>+++>+<<<<-]>+>+>->>+[<]<-]>>.>---.+++++++..+++.>>.<-.<.+++.------.--------.>>+.>++." | bf /dev/stdin
Hello World!

Look... i can explain, i had the same facial expression as you right now, you may probably asking yourself "ALL THIS TO PRINT 'Hello Word' ? ARE YOU CRAZY".

Yes... that's true... BUT WAIT, don't go yet please XD, i have some good news for you down there.

If you're still there, it's a good news, you want to know more, thanks for that mate.

We're going to breakdown that weird ALIEN bash command line written up there :

However i really needed to see how i was manipulating memory blocks, i mean, a kind of memory representation of how the rules i just written were actually affecting the memory.

FIRST STEP (a BRAINFUCK MEMORY VISUALIZER)

I choosed to use a high level programming language to achieve that, the C programming language, sorry JS devs, "not today".

But first, we need to undestand some few stuffs... like standard I/O streams.

WHAT ARE /dev/stdin, /dev/stdout, /dev/stderr ?

The following listed, are standard I/O stream, you can get to know more HERE.

Programs use them to get input, send output after some execution and also , error output to another stream.

So, since i wanted to still "test out" my code using bf, i had to use in my code fprintf and printf, with fprintf printing the built memory representation into the standard error stream with fprintf(stderr, "to stderr stream"); and since printf automatically send to the standard output stream, i had everything on hands.

For a better overview of what am talking about in this example:

#include <stdio.h>
#include <stdlib.h>

int main() {
    fprintf(stderr, "\nto stderr");
    printf("\nto stdout");

    return 0;
}

And as you can test out :

$ gcc ./test.c -o ./test

$ ./test 2> error.txt # getting the stderr into error.txt
to stdout

$ ./test 1> out.txt # getting the stdout into out.txt
to stderr

$ cat ./out.txt
to stdout

$ cat ./error.txt
to stderr

THE PLAN I HAD IN MIND

I wanted a simple program, so that at the end i could be able to do :

$ ./bv ">>+<-" | bf /dev/stdin
# Have the memory representation of those operations (in the stderr),
# then bf intepreator running the actual code (took from bv stdout)

I knew at some point i would have to use a Stack Datastructure(LIFO),

Let's recap, what i wanted to achieve for bv :

LET's CODE

typedef struct Stack {
    int items[MAX_STACK_SIZE];
    int top;
} Stack;

void init_stack(Stack* s) {
    s->top = -1;
}

int is_empty(Stack* s) {
    return s->top == -1;
}

void push(Stack* s, int value) {
    if (s->top >= MAX_STACK_SIZE - 1) {
        fprintf(stderr, "Woups: Stack overflow\n");
        exit(1);
    }
    s->items[++s->top] = value;
}

int pop(Stack* s) {
    if (!is_empty(s)) {
        return s->items[s->top--];
    }

    fprintf(stderr, "Woups: Stack underflow\n");
    exit(1);
}

was enought,no need to over-complicated things for now.

void display_memory(int memory[], int mem_pointer, int size) {
    fprintf(stderr, "\n-------------\nmemory blocks\n-------------\n");
    for (int i = 0; i < size; ++i) {
        fprintf(stderr, "[%d]", memory[i]);
    }
    fprintf(stderr, "\n");

    // fr pointer position
    for (int i = 0; i < mem_pointer; ++i) {
        fprintf(stderr, "    ");
    }
    fprintf(stderr, "^\n");
    fprintf(stderr, "memory pointer\n--------------\n\n");
}

that will display the memory blocks and also the memory pointer(cursor) position.

int memory_shift_printer(const char *input) {

    int memory[MAX_MEMORY_SIZE] = {0};
    int mem_pointer = 0;

    Stack stack;
    init_stack(&stack);

    for (size_t i = 0; i < strlen(input); ++i) {
        // yes, that's a lot of if/else... i don't care, what you gonna do ?
        if (input[i] == '>' && mem_pointer < MAX_MEMORY_SIZE - 1) {
            mem_pointer++;
        } else if (input[i] == '<' && mem_pointer > 0) {
            mem_pointer--;
        } else if (input[i] == '+') {
            memory[mem_pointer]++;
        } else if (input[i] == '-' && memory[mem_pointer] > 0) {
            memory[mem_pointer]--;
        } else if (input[i] == '[') {
            if (memory[mem_pointer] != 0) {
                push(&stack, i);
                continue;
            }

            int loop = 1;
            while (loop > 0) {
                i++;
                if (i == strlen(input)) {
                    fprintf(stderr, "Woups: Mismatched brackets\n");
                    return 1;
                }
                if (input[i] == '[') loop++;
                if (input[i] == ']') loop--;
            }
        } else if (input[i] == ']') {
            if (memory[mem_pointer] == 0) {
                pop(&stack);
            }
            if (is_empty(&stack)) {
                fprintf(stderr, "Woups: Mismatched brackets\n");
                return 1;
            }
            // to be sure move to the command after the matching [
            i = stack.items[stack.top] - 1;
        }

        // for verbose purpose... i can uncomment this to see, what happens at each step.
        // display_memory(memory, mem_pointer, MAX_MEMORY_SIZE);
    }
    display_memory(memory, mem_pointer, MAX_MEMORY_SIZE);
    return 0;
}

pretty simple right ?

I added some comments where it can be confusing to get what's going on.this is not complicated YET, for what's comming in future parts.

#include <stdio.h>
#include <string.h>
#include <stdlib.h>

#define MAX_MEMORY_SIZE 50

// code below...

int main(int argc, char *argv[]) {
    if (argc < 2) {
        fprintf(stderr, "Usage: %s <brainfuck_code>\n", argv[0]);
        return 1;
    }

    char *input = argv[1];
    memory_shift_printer(input);

    return 0;
}

and we have our brainfuck code VISUALIZER ready, just last step, compile and run :

$ gcc -std=c11 ./bv.c -o ./bv
dk:~
$ ./bv ">>>++[<+++>-]+<++<"

-------------
memory blocks
-------------
[0][0][8][1][0][0][0][0][0][0]
   ^
memory pointer
--------------

NICE !!!

We can see our memory blocks array, the memory pointer(cursor) on the last operation too.

And since it' turing complete, you can also do mathematical operation with it :

$ ./bv ">+++[-<+>]>>." | bf /dev/stdin

-------------
memory blocks
-------------
[3][0][0][0][0][0][0][0][0][0][0][0][0]
         ^
memory pointer
--------------

FLAWS (AS A DISCLAIMER)

This C code is not optimal on Part 1, and will be optimized in next future parts, for instance, you can not do :

$ ./bv "++++++++[>++++[>++>+++>+++>+<<<<-]>+>+>->>+[<]<-]>>.>---.+++++++..+++.>>.<-.<.+++.------.--------.>>+.>++." | bf /dev/stdin
Woups: Stack overflow

And that is the input code for "Hello World!" message.

Maybe some of you already found the flaws and ways to optimize the code (but it's the part of the game ;)).

You can get the full first version of the source code HERE

CONCLUSION | END OF PART 1

I hope you enjoyed this first part of a serie of 3 about the brainfuck password generator am building.

In the Next step, we will do two main things :

So keep in touch ;)
