Garou looking just as surprised as you are that this series still exists.

HOW TO MAKE A PASSWORD GENERATOR USING BRAINFUCK (PART 2 / 3)

2025-06-29 11:20 PM • 15 min read • #bash #brainfuck #terminal #c

NOTE: Before you dive in, make sure you’ve read Part 1, otherwise nothing here will make sense, and you’ll blame me, and I’ll blame coffee.


JEEEZZZZ, Seven. Months. Later hun...

Yes, yes, I know, that’s longer than a celebrity marriage.

My laziness defeated my “weekly” motivation, but we’re back, so let’s fry our brains once more!


OBJECTIVES (a.k.a. “Why am I still doing this?”)

  1. Patch a few Brainfuck mysteries we glossed over in Part 1.
  2. Fix our glitchy BV (Brainfuck Visualizer).
  3. Summon CHAOS, a.k.a. randomness, for password fun.
  4. Sneak-peek a shiny new Password Generator.

BRIEF RECAP

Since i got some questions from the precedent part... let's answer some,

“Can you explain Brain-fck in one sentence?”

Imagine an infinitely long tape.> and < scoot your cursor along it,+ and - raise or lower the current cell’s value,[ and ] loop like a hamster wheel,, and . handle input/output,Voilà, that’s Brainfuck.

(Okay, two sentences. Sue me.)


“How do numbers become ‘Hello World’?”

Short answer: ASCII sorcery.

$ echo "++++++++[>++++[>++>+++>+++>+<<<<-]>+>+>->>+[<]<-]>>.>---.+++++++..+++.>>.<-.<.+++.------.--------.>>+.>++." | bf /dev/stdin
Hello World!

When a cell hits, say, 72, the interpreter calls putchar(72), and … boom, H appears.

Need proof?

# Bash one-liner
$ echo $(printf \\$(printf '%03o' 72))
H

Or, if you still trust C:

#include <stdio.h>
int main() {
    putchar(72);  // H
    putchar(101); // e
    putchar(121); // y
    putchar(10);  // \n
}

Compile, run, enjoy:

$ gcc hey.c -o hey && ./hey
Hey

So the Brainfuck tape [72][101][10] spells “Hey”, and the minimal BF to do that is:

-[------->+<]>-.-[->+++++<]>++.[--->+<]>++.

Magic? Nope, just lovingly-abused pointers.


WHAT WAS WRONG WITH OUR BV?

In Part 1 we heroically ignored , and . because simplicity (lazy demons in me).

We also assumed a 1-D tape (boring) and left the code about as stable as a Jenga tower in an earthquake.

Run the classic “Hello World” through the old BV and it coughs up mismatched brackets and existential dread. Time for a refactor.


Triage & Tweaks

  1. Shrink memory to the sane-ish 30 000 cells.
  2. Dynamic stack, no more hard-wiring the call depth.
  3. Cache strlen once; your CPU thanks you.
  4. Show only the juicy cells around the pointer.
  5. Detect bracket mismatches before they detect you.
  6. Beam me up, Z-axis, yes, we upgraded to a 3-D tape for extra madness.

Key Surgery (highlight reel)

Below are tiny snippets, full code’s at the end if you’re a masochist.

#define MEMORY_DEPTH 2    // New Z-axis
#define MEMORY_ROWS  7
#define MEMORY_COLS  8    // X-axis

// Dynamic stack because recursion isn’t the only way to segfault
typedef struct Stack {
    int *items;
    int  top;
    int  capacity;
} Stack;
void display_memory(int mem[][MEMORY_ROWS][MEMORY_COLS],
                    int d, int r, int c) {
    fprintf(stderr, "----- Memory -----\n");
    for (int z = 0; z < MEMORY_DEPTH; z++) {
        fprintf(stderr, "\nLayer %d\n", z);
        for (int y = 0; y < MEMORY_ROWS; y++) {
            for (int x = 0; x < MEMORY_COLS; x++) {
                fprintf(stderr, "[%2d]", mem[z][y][x]);
            }
            if (z == d && y == r) {
                // cute arrow
                for (int x = 0; x < MEMORY_COLS; x++)
                    fprintf(stderr, x == c ? " ^ " : "   ");
            }
            fprintf(stderr, "\n");
        }
    }
}
case '[':                      // Enter loop
    if (cell) push(&stack, i); // remember where we came from
    else       SKIP_TO_MATCH(); // jump over the loop
    break;
case ']':                      // Exit loop
    if (is_empty(&stack)) PANIC("Mismatched ]");
    if (cell) i = peek(&stack); // loop again
    else      pop(&stack);
    break;

Want the entire 350-line beast? keep scrolling to the appendix.


SUMMONING CHAOS (Randomness 101)

A password generator without randomness is just predictable sadness.Next time we’ll wire up entropy sources, sprinkle in /dev/urandom, and let Brainfuck dance.

Teaser:

unsigned char random_byte(void) {
    FILE *f = fopen("/dev/urandom", "rb");
    unsigned char b;
    fread(&b, 1, 1, f);
    fclose(f);
    return b;
}

Yes, Windows folks, you’ll need another trick, stay tuned (and pray...).


FIRST GLIMPSE AT THE PASSWORD GENERATOR

Picture this:

$ ./bf-pwgen 16
9Yf%kC+u@w$r4LzQ

More on that in Part 3, where we’ll:

  1. Fold randomness into Brainfuck loops.
  2. Export passwords to stdout and a QR code (because why not).
  3. Benchmark against real generators, and maybe win?

DEMO (SHOW TIIIIMME)

On a 3D Visualization for two grid, the bf visualizer works like this :


FULL SOURCE (Appendix)

Click to expand 340 lines of weird C code written by a weird nerd.

Warning: long code ahead. Skip if you value your retina and you have a life.

#include <stdio.h>
#include <stdlib.h>
#include <string.h>
#include <unistd.h>

#define MEMORY_DEPTH 2   // New depth size for the z-axis
#define MEMORY_ROWS 7    // Define vertical size
#define MEMORY_COLS 8   // Define horizontal size

typedef struct Stack {
    int* items;
    int top;
    int capacity;
} Stack;

void init_stack(Stack* s, int capacity) {
    s->items = (int*)malloc(capacity * sizeof(int));
    if (!s->items) {
        fprintf(stderr, "Woups: Memory allocation failed for stack\n");
        exit(1);
    }
    s->top = -1;
    s->capacity = capacity;
}

void free_stack(Stack* s) {
    free(s->items);
}

int is_empty(Stack* s) {
    return s->top == -1;
}

void push(Stack* s, int value) {
    if (s->top >= s->capacity - 1) {
        fprintf(stderr, "Woups: Stack overflow\n");
        exit(1);
    }
    s->items[++s->top] = value;
}

int pop(Stack* s) {
    if (is_empty(s)) {
        fprintf(stderr, "Woups: Stack underflow\n");
        exit(1);
    }
    return s->items[s->top--];
}

void display_memory(int memory[][MEMORY_ROWS][MEMORY_COLS], int depth_pointer, int row_pointer, int col_pointer) {
    fprintf(stderr, "----- Memory Block Display ------\n");

    for (int depth = 0; depth < MEMORY_DEPTH; ++depth) {
        fprintf(stderr, "\n________________________________%d\n", depth); // depth

        for (int row = 0; row < MEMORY_ROWS; ++row) {
            fprintf(stderr, "|");  // Labeling rows

            for (int col = 0; col < MEMORY_COLS; ++col) {
                if (memory[depth][row][col] != 0) {
                    fprintf(stderr, "[%2d]", memory[depth][row][col]); // Proper spacing
                } else {
                    fprintf(stderr, "[  ]");  // For alignment of zero values
                }
            }
            fprintf(stderr, "\n");

            // Print the pointer only in relevant row and depth
            if (depth == depth_pointer && row == row_pointer) {
                for (int col = 0; col < MEMORY_COLS; ++col) {
                    if (col == col_pointer) {
                        // TODO: uncomment this if needed
                        fprintf(stderr, "   ^  ");  // Arrow pointing to the current cell
                    } else {
                        fprintf(stderr, "    ");  // Filler for alignment consistency
                    }
                }
                // TODO: uncomment this if needed
                fprintf(stderr, "\n");
            }
        }
    }
    fprintf(stderr, "---------------------------------\n");
}

int memory_shift_printer(const char *input) {
    int memory[MEMORY_DEPTH][MEMORY_ROWS][MEMORY_COLS] = {{{0}}}; // Initialize 3D array
    int depth_pointer = 0;
    int row_pointer = 0;
    int col_pointer = 0;

    Stack stack;
    init_stack(&stack, 1024);
    size_t input_length = strlen(input);

    for (size_t i = 0; i < input_length; ++i) {
        switch (input[i]) {
            case '>':
                if (col_pointer < MEMORY_COLS - 1) col_pointer++;
                break;
            case '<':
                if (col_pointer > 0) col_pointer--;
                break;
            case '+':
                memory[depth_pointer][row_pointer][col_pointer]++;
                break;
            case '-':
               if (memory[depth_pointer][row_pointer][col_pointer] > 0) memory[depth_pointer][row_pointer][col_pointer]--;
                break;
            case '^':  // Move up in the memory matrix
                if (row_pointer > 0) row_pointer--;
                break;
            case 'v':  // Move down in the memory matrix
                if (row_pointer < MEMORY_ROWS - 1) row_pointer++;
                break;
            case '~':  // Move between depths in the memory matrix
                if (depth_pointer < MEMORY_DEPTH - 1) depth_pointer++;
                break;
            case '%':  // Move backward between depths in the memory matrix
                if (depth_pointer > 0) depth_pointer--;
                break;
            case '[':
                if (memory[depth_pointer][row_pointer][col_pointer] != 0) {
                    push(&stack, i);
                } else {
                    int loop = 1;
                    while (loop > 0) {
                        if (++i == input_length) {
                            fprintf(stderr, "Woups: Mismatched brackets\n");
                            free_stack(&stack);
                            return 1;
                        }
                        if (input[i] == '[') loop++;
                        if (input[i] == ']') loop--;
                    }
                }
                break;
            case ']':
                if (is_empty(&stack)) {
                    fprintf(stderr, "Woups: Mismatched brackets\n");
                    free_stack(&stack);
                    return 1;
                }
                if (memory[depth_pointer][row_pointer][col_pointer] != 0) {
                    i = stack.items[stack.top];
                } else {
                    pop(&stack);
                }
                break;
        }

        system("clear");
        display_memory(memory, depth_pointer, row_pointer, col_pointer);
        usleep(40000);
    }

    free_stack(&stack);
    return 0;
}

int main(int argc, char *argv[]) {
    if (argc < 2) {
        fprintf(stderr, "Usage: %s <brainfuck_code>\n", argv[0]);
        return 1;
    }

    char *input = argv[1];
    memory_shift_printer(input);

    printf("%s\n", input);

    return 0;
}

(If the scroll wheel starts smoking, you’ve found the end.)


WRAP-UP

You survived Part 2, WAOUW !

We fixed the visualizer, dipped our toes into randomness, and prepped the battlefield for a full-blown Brainfuck password generator.

Next stop: Part 3, where entropy meets insanity.

Until then, may your brackets always match and your pointers never segfault.

You can now jump to Part3

Or go back in time on Part1
